Subodh Sarkar

DIY Fast EV Charger 22kW (eBook, ePUB)

• Format: ePub

Produktbeschreibung

This is a practical electronics product manufacturing eBook focused on a DIY (Do-It-Yourself) project, authored by an IIT Engineer. It provides instructions to build a "Fast EV Charger - Type 2 - 22kW - AC-3phase-LCD Display". The eBook includes a complete design package for constructing an EV Charger either for personal use or as a marketable product. The addition of a Nextion 3.5" TFT LCD Display allows the user to view images during the EV Charger operation, adding functional and aesthetic value to the product.

Electronics product design requires knowledge of hardware and software, along with industrial experience. The author has over 45 years of industry experience and has published several notable eBooks, including four important ones.

You'll be able to build a Fast EV Charger 22Kw 3phase AC with the help of this eBook only. If you have 3-phase power available at home, you can build yourself and install a 3-phase EV charger for faster charging. If you own a Public Charging Station, you can install 3-phase AC charging.

3-phase power provide a higher voltage and current compared to single-phase, allowing for faster charging. In Europe, 3-phase power is more common in residential settings, making it easier to install fast EV chargers.

This eBook is very useful for both young and experienced engineer who are engaged in designing Electric Vehicle Chargers. This comprehensive eBook will enable engineers to independently develop market-leading Fast EV Chargers of exceptional quality.

Building a 22kW 3-phase AC Fast EV Charger involves meeting safety standards and regulatory compliance. Each phase needs protection against various electrical faults, including high/low input voltage, maximum output current, surges, and ground faults. We use separate Safety Interlocks Cards for each phase to meet these requirements. The design has been evaluated with actual electric vehicles. This eBook provides clear wiring diagrams and technical information that is accessible to both beginner and experienced engineers.

This eBook contains seven chapters, 19 downloadable resource design files, 72 engineering images, downloadable Gerber files for six PCBs, a complete bill of materials, and complete manufacturing files for Model: EDP-O1C. It also includes calibration and test procedures for Model: EDP-01C.

Chapter 1 covers the core technology of electric vehicle chargers. Chapter 2 details the product's technical specifications. Chapter 3 simplifies the Fast EV charger with a Block Diagram.

Chapter 4 focuses on the motherboard, including schematics, PCB designs, Gerber files, BOM, and Arduino codes. Chapter 5 provides documentation for other components like safety interlocks card, Nextion Driver Card, RFID control card, and Bluetooth control card.

Chapter 6 discusses manufacturing processes, Nextion display images, Door plate interconnections, EV charger simulator fabrication, mobile app details, and smart card creation. Chapter 7 outlines calibration and test procedures to ensure high performance and safety standards.

Buy this Book and just follow all the steps. When all the Steps are finished, you'll have a Fully Tested working model of a marketable Fast EV Charger 22kW 3-Phase AC.

---

Dieser Download kann aus rechtlichen Gründen nur mit Rechnungsadresse in A, B, CY, CZ, D, DK, EW, E, FIN, F, GR, H, IRL, I, LT, L, LR, M, NL, PL, P, R, S, SLO, SK ausgeliefert werden.

Produktdetails

• Verlag: Subodh Sarkar
• Erscheinungstermin: 15. April 2025
• Englisch
• ISBN-13: 9798224779994
• Artikelnr.: 73911470

Autorenporträt

I am a Graduate Electronics Engineer from Indian Institute of Technology, Kharagpur, India having more than 45 years of Design Engineering experience in Electronics Products. I have worked in multi-discipline industries which helped me to understand the design criteria of Electronics Products using advanced technology.

Electronics Product design requires a strong knowledge of both hardware and software in electronics and it is to be blended with practical industrial experience. I wrote some eBooks and two of them are worth mentioning here. The first one is "Electric Vehicle Service Equipment EVSE Comprehensive Design Inputs of Level 1, 2 & 3 Chargers: Circuits, Design & Infrastructure of EVSE" which was published in Amazon. The second one is "Lithium-Ion Battery the Power of Electric Vehicles: Basics, Design, Charging technology & Battery Management Systems" which was published in Smashwords. Both the eBooks were largely sold.

I provide 'Advanced Electronics Engineering Products Technology' to manufacturers of Electronics Products. Advanced technology in electronics hardware engineering is costly and difficult to procure. Being an EX-IITan with more than 45+ years of industrial expertise, I am in the market to sell costly advanced technology at a throw away price to help world wide manufacturers in electronics sector.

I am highly experienced in Electronics Product Design and manufacturing. Whether you're a startup seeking guidance or an established company with specific requirements, I am here to assist you.

Thanks and regards,

Subodh Sarkar,

B.Tech (Hons), IIT-KGP.
